Double Function Land Mining Machinery Foe Gold and Diamond

Model NO. : LM-11

Material : Carbon Steel

Material Feature : Corrosion Resistant

Certification : ISO9001:2008, ISO9001:2000, CE

Energy Saving : Energy Saving

Warranty : 2 Years

Color : Multi Color

Customized : Customized

Condition : New

After-sales Service : Lifelong Service

Application : Land Gold and Diamond

Capacity : 1-500ton /Hour

Power System : Generator Sets

Scrrening System : Electric Motor

Production Gold Capacity : 99%

Warrant : 2 Year

Total Length : 4-20 M

Gold Recovery System : Agitation Chute and Jigging

Diamond Recovery System : Centrifuge

Transport Package : Canvas

Specification : Capacity 1ton-500ton

Trademark : Aoerheng

Origin : China

HS Code : 8474100000

Production Capacity : 50000 Set /Year

Contact Now

Double function land mining machinery foe gold and diamond

1. Land Mining machinery brief:

Land mining machinery are consist of feeding system . screening system . selecting gold and diamond system generator sets system reply water system . according to the different feeding way . there are excavator . belt conveyor so on . screening system is according to the screen request to design different mesh . according to the processing different material to choose the agitation chute with fixed chut .jigging and centrifuge so on . generator sets provide all electric power for motor . High pressure water pump offer water for whole system .

2. Land mining machinery main picture :

3.Main parts introuduce :
Double Function Land Mining Machinery Foe Gold and Diamond

4.Basic parameter :

1) TGM-1200 Gold Trommel Screen
- High capacity.75-120m³/h
- Gold recovery rate to be proved higher than 97%
- Can be move easily
- Maximize design life
- Suitable for remote area.
- Need a minimum of operator
- Lower operating and maintenance cost.

NO	item	specification
1	Overall length	7m
2	Overall width	2.3m
3	Overall height	3.3m
4	Trommel diameter	1.2m
5	Table area	2.8 m3
6	Table riffies	Rubber table riffies
7	Capacity	75-120m3/h
8	Trommel mesh diameter	6-10mm
9	Power	7.5kw*4
10	Water pump	8 inch
11	Water flow	400m3/h
12	Head	32m
13	Rated power	52kw
14	Rated speed	1500r/min
15	Operator	one person
16	Fuel consumption	12.8L/H

2)TGM-1800
The mainframe is made by whole welding process.
- Equipped heavyduty slide with wear proof backplate
- Easy to move the trommel machine
- With belt conveyor to collect taillings,Motor driving, spees adjiust by transducer
- Water supply system in the hopper
- Head and tail equipt the traction handle
- Need a minimum of operators
- Lower operating and maintenance cost
- Diesel engine can choose WEICHAI,Cummins Brand
- The equipment is particularly suitable for the remote areas.

NO	item	specification
1	Overall length	21.4m
2	Overall width	11.1m
3	Overall height	5.05m
4	Trommel diameter	1.8m
5	Screen area	22m2
6	Sluice area	2*9m2
7	Capacity	150-200m3/h
8	Trommel mesh diameter	6.3mm
9	Sluice mat	Rubber mat
10	Hopper	Board thickness 8mm.6mm rubber lining
11	Belt conveyor Power	7.5kw*4
12.	Drum screen power	15kw*4
13	Water pump	12 inch
14	Water flow	1000m3/h
15	Head	32m
16	Rated power	150kw
17	Rated speed	1500r/min
18	Operator	one person
19	Fuel consumption	33.82L/H
20	Generator set	Diesel engine power

5.Fine machinery :

6.Land mining machinery feature :

1	Low failure maintance easily .
2	Durable steel plate made and high quality brand device
3	High processing capacity and hign extraction ratio
4	Saving water and labor . one person can control
5	Installation easy . operation easy .

7. Our service :

we can offer the solution and design before the sale, we can customize according to your request and need .

we can offer the one year after- service and the professional enginner for our customers.

we can provide the detail installing guidance,overall commissioning, prejob training and solving of the diffcult problem.

8. Our customers :
Double Function Land Mining Machinery Foe Gold and Diamond

9. Our factory :
Aoerheng factory covers an area of more than 20,000 square meters. The company adopts modern enterprise management concept, seiko manufacturing, forge ahead. The company has strong technical force, advanced technology, complete varieties, strictly according to the ISO9001 standard, organization, design, production, sales and management.

Aoerheng Company sets scientific research and development, engineering design, installation, debugging, production services for the integration of integrated enterprise, the domestic products to death of livestock and poultry disposal equipment, life garbage disposal equipment, eat hutch waste disposal equipment, food processing equipment, medical wastes treatment equipment, sludge treatment equipment, all kinds of equipment such as solid waste processing products. And according to customer needs, design and customize all kinds of efficient and practical equipment and production lines.
